BS EN 60191-6-12:2011 Mechanical standardization of semiconductor devices General rules for the preparation of outline drawings of surface mounted semiconductor device packages. Design guidelines for fine-pitch land grid array (FLGA)

BS EN 60191-6-12:2011

Mechanical standardization of semiconductor devices General rules for the preparation of outline drawings of surface mounted semiconductor device packages. Design guidelines for fine-pitch land grid array (FLGA)

Format
Availability
Price and currency
English Secure PDF
Immediate download
258.84 USD
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
25.88 USD
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
77.65 USD
English Hardcopy
In stock
258.84 USD
Standard number:BS EN 60191-6-12:2011
Pages:24
Released:2011-08-31
ISBN:978 0 580 70310 2
Status:Standard
DESCRIPTION

BS EN 60191-6-12:2011


This standard BS EN 60191-6-12:2011 Mechanical standardization of semiconductor devices is classified in these ICS categories:
  • 01.100.25 Electrical and electronics engineering drawings
  • 31.080.01 Semiconductor devices in general
IEC 60191-6-12:2011 provides standard outline drawings, dimensions, and recommended variations for all fine-pitch land grid array packages (FLGA) with terminal pitch of 0,8 mm or less. This edition includes the following significant changes with respect to the previous edition:
- scope is expanded so that this standard include the square type FLGA. The title of this standard has been changed accordingly: "Rectangular type" has been deleted from the title;
- ball pitch of 0,3 mm has been added;
- datum is changed from the body datum to the ball datum;
- combination lists of D, E, MD, and ME have been revised.
