immediate downloadReleased: 2014-02-28
BS EN 60317-38:2014 Specifications for particular types of winding wires Polyester or polyesterimide overcoated with polyamide-imide, enamelled round copper wire, class 200, with a bonding layer

BS EN 60317-38:2014

Specifications for particular types of winding wires Polyester or polyesterimide overcoated with polyamide-imide, enamelled round copper wire, class 200, with a bonding layer

Format
Availability
Price and currency
English Secure PDF
Immediate download
195.00 USD
English Hardcopy
In stock
195.00 USD
Standard number:BS EN 60317-38:2014
Pages:16
Released:2014-02-28
ISBN:978 0 580 75755 6
Status:Standard
DESCRIPTION

BS EN 60317-38:2014


This standard BS EN 60317-38:2014 Specifications for particular types of winding wires is classified in these ICS categories:
  • 29.060.10 Wires

This part of IEC 60317 specifies the requirements of enamelled round copper winding wire of class 200 with a triple coating. The underlying coating is based on polyester or polyesterimide resin, which may be modified providing it retains the chemical identity of the original resin and meets all specified wire requirements. The secondary coating is based on polyamide-imide resin. The third coating is a bonding layer based on a thermoplastic or thermosetting resin.

NOTE A modified resin is a resin that has undergone a chemical change, or contains one or more additives to enhance certain performance or application characteristics.

The range of nominal conductor diameters covered by this part is:

  • Grade 1B: 0,050 mm up to and including 1,600 mm;

  • Grade 2B: 0,050 mm up to and including 1,600 mm.

The nominal conductor diameters are specified in Clause 4 of IEC 60317-0-1:2013.
