BS EN 60603-7-2:2010
Connectors for electronic equipment Detail specification for 8-way, unshielded, free and fixed connectors, for data transmissions with frequencies up to 100 MHz
| Standard number: | BS EN 60603-7-2:2010 |
| Pages: | 18 |
| Released: | 2010-08-31 |
| ISBN: | 978 0 580 67359 7 |
| Status: | Standard |
| Pages (English): | 18 |
| ISBN (English): | 978 0 580 67359 7 |
BS EN 60603-7-2:2010
This standard BS EN 60603-7-2:2010 Connectors for electronic equipment is classified in these ICS categories:
- 35.240.50 IT applications in industry
- 25.040.01 Industrial automation systems in general
- 31.220.10 Plug-and-socket devices. Connectors
This part of IEC 60603 covers 8-way, unshielded, free and fixed connectors, references dimensional, mechanical, electrical and environmental characteristics and tests in IEC 60603-7, and specifies electrical transmission requirements for frequencies up to 100 MHz. These connectors are typically used as category 5 connectors in class D cabling systems specified in ISO/IEC IS 11801.
These connectors are intermateable and interoperable with other IEC 60603-7 series connectors as defined in Clause 2 of IEC 60603-7.
These connectors are backward compatible with other IEC 60603-7 series connectors.
NOTE Transmission performance categories: in this IEC standard, the term “category”, when used in reference to transmission performance, refers to those categories defined by ISO/IEC 11801.
