BS EN 61557-8:2015 Electrical safety in low voltage distribution systems up to 1 000 V a.c. and 1 500 V d.c. Equipment for testing, measuring or monitoring of protective measures Insulation monitoring devices for IT systems

BS EN 61557-8:2015

Electrical safety in low voltage distribution systems up to 1 000 V a.c. and 1 500 V d.c. Equipment for testing, measuring or monitoring of protective measures Insulation monitoring devices for IT systems

Format
Availability
Price and currency
English Secure PDF
Immediate download
386.67 USD
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
38.67 USD
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
116.00 USD
English Hardcopy
In stock
386.67 USD
Standard number:BS EN 61557-8:2015
Pages:52
Released:2016-06-30
ISBN:978 0 580 81262 0
Status:Standard
DESCRIPTION

BS EN 61557-8:2015


This standard BS EN 61557-8:2015 Electrical safety in low voltage distribution systems up to 1 000 V a.c. and 1 500 V d.c. Equipment for testing, measuring or monitoring of protective measures is classified in these ICS categories:
  • 17.220.20 Measurement of electrical and magnetic quantities
  • 29.080.01 Electrical insulation in general
  • 29.240.01 Power transmission and distribution networks in general

This part of IEC 61557 specifies the requirements for insulation monitoring devices (IMD) which permanently monitor the insulation resistance R F to earth of unearthed a.c. IT systems, of a.c. IT systems with galvanically connected d.c. circuits having nominal voltages up to 1 000 V a.c., as well as of unearthed d.c. IT systems with voltages up to 1 500 V d.c. independent from the method of measuring.

IT systems are described in IEC 60364‑4‑41 amongst other literature. Additional data for the selection of devices in other standards should be noted.

NOTE

Various standards specify the use of IMDs in IT systems. In such cases, the objective of the equipment is to signal a drop in insulation resistance R F below a minimum limit.

IMDs according to this part of IEC 61557 can also be used for de-energized TT, TN and IT systems or appliances.
