immediate downloadReleased: 2017-05-24
BS EN 62196-2:2017 Plugs, socket-outlets, vehicle connectors and vehicle inlets. Conductive charging of electric vehicles Dimensional compatibility and interchangeability requirements for a.c. pin and contact-tube accessories

BS EN 62196-2:2017

Plugs, socket-outlets, vehicle connectors and vehicle inlets. Conductive charging of electric vehicles Dimensional compatibility and interchangeability requirements for a.c. pin and contact-tube accessories

Format
Availability
Price and currency
English Secure PDF
Immediate download
349.98 USD
English Hardcopy
In stock
349.98 USD
Standard number:BS EN 62196-2:2017
Pages:68
Released:2017-05-24
ISBN:978 0 580 87759 9
Status:Standard
DESCRIPTION

BS EN 62196-2:2017


This standard BS EN 62196-2:2017 Plugs, socket-outlets, vehicle connectors and vehicle inlets. Conductive charging of electric vehicles is classified in these ICS categories:
  • 29.120.30 Plugs, socket-outlets, couplers
  • 43.120 Electric road vehicles

This part of IEC 62196 applies to plugs, socket-outlets, vehicle connectors and vehicle inlets with pins and contact-tubes of standardized configurations, herein referred to as accessories. They have a nominal rated operating voltage not exceeding 480 V a.c., 50 Hz to 60 Hz, and a rated current not exceeding 63 A three-phase or 70 A single phase, for use in conductive charging of electric vehicles.

This part of IEC 62196 covers the basic interface accessories for vehicle supply as specified in IEC 62196‑1 , and intended for use in conductive charging systems for circuits specified in IEC 61851‑1:2010 .

NOTE 1

Electric road vehicles (EV) implies all road vehicles, including plug-in hybrid road vehicles (PHEV), that derive all or part of their energy from RESS.

These accessories are intended to be used for circuits specified in IEC 61851‑1:2010 which operate at different voltages and frequencies and which may include extra-low voltage (ELV) and communication signals.

These accessories may be used for bidirectional power transfer (under consideration).

This standard applies to accessories to be used in an ambient temperature between –30 °C and +50 °C.

NOTE 2

In the following country, other requirements regarding the lower temperature may apply: NO.

NOTE 3

In the following country, –35 °C applies: SE.

These accessories are intended to be connected only to cables with copper or copper-alloy conductors.

Vehicle inlet and vehicle connector to this standard are intended to be used for charging in modes 1, 2 and 3, cases B and C. The socket-outlets and plugs covered by this standard are intended to be used for charging mode 3 only, case A and B.

The modes and permissible connections are specified in IEC 62196‑1:2014 .
