BS EN IEC 61169-68:2022 Radio-frequency connectors Sectional specification for series TRK bayonet coupling triaxial connectors

BS EN IEC 61169-68:2022

Radio-frequency connectors Sectional specification for series TRK bayonet coupling triaxial connectors

Format
Availability
Price and currency
English Secure PDF
Immediate download
281.85 USD
English Hardcopy
In stock
281.85 USD
Standard number:BS EN IEC 61169-68:2022
Pages:34
Released:2022-06-10
ISBN:978 0 539 05282 4
Status:Standard
DESCRIPTION

BS EN IEC 61169-68:2022


This standard BS EN IEC 61169-68:2022 Radio-frequency connectors is classified in these ICS categories:
  • 33.120.30 RF connectors
This part of IEC 61169, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for series TRK bayonet coupling triaxial connectors. The series TRK bayonet coupling triaxial connectors having the advantages of quick connection and separation, high reliability, small size, good salt characteristics, four polarizations to prevent error-mate etc., can be connected to symmetrically twisted pair cables or triaxial cables. They have been widely used in 1553B data bus systems or other communication systems for digital signal transmission. It specifies mating face dimensions for series TRK bayonet coupling triaxial connectors, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series TRK triaxial connectors. This document indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H. NOTE Metric dimension are original dimensions. All undimensioned pictorial configurations are for reference purpose only.
