>BSI Standards >17 METROLOGY AND MEASUREMENT. PHYSICAL PHENOMENA>17.040 Linear and angular measurements>17.040.40 Geometrical Product Specification (GPS)>BS EN ISO 16610-22:2026 - TC Tracked Changes. Geometrical product specifications (GPS). Filtration Linear profile filters: Spline filters
immediate downloadReleased: 2026-03-31
BS EN ISO 16610-22:2026 - TC Tracked Changes. Geometrical product specifications (GPS). Filtration Linear profile filters: Spline filters

BS EN ISO 16610-22:2026 - TC

Tracked Changes. Geometrical product specifications (GPS). Filtration Linear profile filters: Spline filters

Format
Availability
Price and currency
English Secure PDF
Immediate download
Printable - You are authorized to print 1 copy
429.55 USD
English Hardcopy
In stock
429.55 USD
Standard number:BS EN ISO 16610-22:2026 - TC
Pages:81
Released:2026-03-31
ISBN:978 0 539 41696 1
Status:Tracked Changes
DESCRIPTION

BS EN ISO 16610-22:2026 - TC


This standard BS EN ISO 16610-22:2026 - TC Tracked Changes. Geometrical product specifications (GPS). Filtration is classified in these ICS categories:
  • 17.040.40 Geometrical Product Specification (GPS)
This document specifies linear spline filters for the filtration of surface profiles. It defines, in particular, how to separate large- and small-scale lateral components of surface profiles. The concepts presented for closed profiles are applicable to the case of roundness filtration. Where appropriate, these concepts can be extended to generalized closed profiles, especially for surface profiles with re-entrant features. Examples for the application of the spline filter are given in Annex A. The influence of the tension parameter  on the large-scale lateral component of the profile is shown in Annex B.
