BS ISO 12165:2019 Tools for moulding. Components of compression and injection moulds and diecasting dies. List of equivalent terms and symbols

BS ISO 12165:2019

Tools for moulding. Components of compression and injection moulds and diecasting dies. List of equivalent terms and symbols

Format
Availability
Price and Currency
English Secure PDF
Immediate download
282.12 USD
English Hardcopy
In stock
282.12 USD
Standard number:BS ISO 12165:2019
Pages:42
Released:2019-11-11
ISBN:978 0 539 00595 0
Status:Standard
DESCRIPTION

BS ISO 12165:2019


This standard BS ISO 12165:2019 Tools for moulding. Components of compression and injection moulds and diecasting dies. List of equivalent terms and symbols is classified in these ICS categories:
  • 25.120.30 Moulding equipment
  • 01.040.25 Manufacturing engineering (Vocabularies)

This document specifies the terms generally in use for components of compression and injection moulds and diecasting dies. The function of these components is shown in Figure 1 to Figure 30.

NOTE

The figures are given as examples.

The purpose of this document is to introduce coherent terms in professional terminology particularly with regard to the use in CAD (Computer Aided Drafting).

Various symbols are specified for simplified representation on technical drawings.


This product includes:
