BS ISO 13041-3:2009 Test conditions for numerically controlled turning machines and turning centres Geometric tests for machines with inverted vertical workholding spindles

BS ISO 13041-3:2009

Test conditions for numerically controlled turning machines and turning centres Geometric tests for machines with inverted vertical workholding spindles

Format
Availability
Price and currency
English Secure PDF
Immediate download
317.20 USD
English Hardcopy
In stock
317.20 USD
Standard number:BS ISO 13041-3:2009
Pages:44
Released:2009-04-30
ISBN:978 0 580 56059 0
Status:Standard
DESCRIPTION

BS ISO 13041-3:2009


This standard BS ISO 13041-3:2009 Test conditions for numerically controlled turning machines and turning centres is classified in these ICS categories:
  • 25.040.20 Numerically controlled machines

ISO 13041-3:2008 specifies, with reference to ISO 230-1 and ISO 230-7, the geometric tests on general-purpose, numerically controlled (NC) turning machines and turning centres with inverted vertical workholding spindles, as well as the corresponding applicable tolerances.

This part of ISO 13041 presents the different concepts or configurations and common features of NC turning machines and turning centres with inverted vertical spindles. It also provides a terminology and designation of controlled axes. (See Figures 1, 2, 3 and 4.)

This part of ISO 13041 deals only with the verification of the accuracy of the machine. It does not apply to the operational testing of the machine (e.g. vibration, abnormal noise, stick-slip motion of components), nor to machine characteristics (e.g. speeds, feeds), as such checks are generally carried out before testing accuracy.
