BS ISO 15217:2000 Fluid power systems and components. 16mm square electrical connector with earth contact. Characteristics and requirements

BS ISO 15217:2000

Fluid power systems and components. 16mm square electrical connector with earth contact. Characteristics and requirements

Format
Availability
Price and currency
English Secure PDF
Immediate download
200.00 USD
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
20.00 USD
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
60.00 USD
English Hardcopy
In stock
200.00 USD
Standard number:BS ISO 15217:2000
Pages:16
Released:2001-01-15
ISBN:0 580 36654 5
Status:Standard
DESCRIPTION

BS ISO 15217:2000


This standard BS ISO 15217:2000 Fluid power systems and components. 16mm square electrical connector with earth contact. Characteristics and requirements is classified in these ICS categories:
  • 23.100.99 Other fluid power system components
  • 29.120.30 Plugs, socket-outlets, couplers

This International Standard specifies the following characteristics and requirements for a general-purpose, electrical-plug connector with two or three contacts plus earth, for use with solenoids:

  • the electrical characteristics of the connector;

  • the dimensions of the contacts;

  • the means of fixing the plug to the socket;

  • the sealing procedure between the plug and the socket;

  • usage requirements.

The electrical-plug connector specified in this International Standard is intended to be used under working conditions such that the connector cannot be damaged by external action (for example, shock or excessive loading).
