immediate downloadReleased: 2015-10-31
BS ISO 19347:2015 Synchronous belt drives. Imperial pitch trapezoidal profile system. Belts and pulleys

BS ISO 19347:2015

Synchronous belt drives. Imperial pitch trapezoidal profile system. Belts and pulleys

Format
Availability
Price and currency
English Secure PDF
Immediate download
317.20 USD
English Hardcopy
In stock
317.20 USD
Standard number:BS ISO 19347:2015
Pages:36
Released:2015-10-31
ISBN:978 0 580 85742 3
Status:Standard
DESCRIPTION

BS ISO 19347:2015


This standard BS ISO 19347:2015 Synchronous belt drives. Imperial pitch trapezoidal profile system. Belts and pulleys is classified in these ICS categories:
  • 21.220.10 Belt drives and their components

This International Standard specifies the principal characteristics of synchronous endless belts and pulleys for use in synchronous endless belt drivesa for mechanical power transmission and where positive indexing or synchronization is required.

The principal characteristics includes the following:

  1. belt nominal tooth dimensions;

  2. belt length and width dimensions and tolerances;

  3. belt length-measurement specifications;

  4. pulley grooves dimensions and tolerances;

  5. pulley dimensions and tolerances;

  6. pulley quality specification.
