immediate downloadReleased: 2018-05-25
BS ISO 3316:2018 Assembly tools for screws and nuts. Attachments for hand-operated square drive socket wrenches. Dimensions and tests

BS ISO 3316:2018

Assembly tools for screws and nuts. Attachments for hand-operated square drive socket wrenches. Dimensions and tests

Format
Availability
Price and currency
English Secure PDF
Immediate download
163.80 USD
English Hardcopy
In stock
163.80 USD
Standard number:BS ISO 3316:2018
Pages:14
Released:2018-05-25
ISBN:978 0 580 99329 9
Status:Standard
DESCRIPTION

BS ISO 3316:2018


This standard BS ISO 3316:2018 Assembly tools for screws and nuts. Attachments for hand-operated square drive socket wrenches. Dimensions and tests is classified in these ICS categories:
  • 25.140.30 Hand-operated tools

This document applies to attachments for hand-operated square drive socket wrenches.

NOTE 1 The attachments for hand-operated square drive socket wrenches covered by this standard are the ones identified in ISO 1703:2018 under reference No. 5 1 00 03 0, 5 1 00 04 0, 5 1 00 04 1 and 5 1 00 05 0.

It specifies

  1. the overall dimensions;

  2. the minimum Rockwell hardness value for their driving squares;

  3. the method of torque testing;

  4. the minimum torsional strength values;

  5. the designation; and

  6. the marking.

NOTE 2 For the specification of square adaptors with a hexagon or cylindrical flat drive, for power socket wrenches, see ISO 3317.
