immediate downloadReleased: 2013-12-31
BS ISO 3320:2013 Fluid power systems and components. Cylinder bores and piston rod diameters and area ratios. Metric series

BS ISO 3320:2013

Fluid power systems and components. Cylinder bores and piston rod diameters and area ratios. Metric series

Format
Availability
Price and currency
English Secure PDF
Immediate download
195.00 USD
English Hardcopy
In stock
195.00 USD
Standard number:BS ISO 3320:2013
Pages:16
Released:2013-12-31
ISBN:978 0 580 80094 8
Status:Standard
DESCRIPTION

BS ISO 3320:2013


This standard BS ISO 3320:2013 Fluid power systems and components. Cylinder bores and piston rod diameters and area ratios. Metric series is classified in these ICS categories:
  • 23.100.20 Cylinders

This International Standard establishes a metric series of cylinder bore and piston rod diameters for hydraulic and pneumatic cylinders, and specifies for each pair of diameters a corresponding standard ratio between the useful areas.

This International Standard applies only to the dimensional criteria of products manufactured in conformity with this International Standard; it does not apply to their functional characteristics.
