BS ISO 8114:1990

This standard BS ISO 8114:1990 Textile machinery and accessories. Spindles for ring-spinning and doubling machines. List of equivalent terms is classified in these ICS categories:

• 59.120.10 Spinning, twisting and texturing machines
• 01.040.59 Textile and leather technology (Vocabularies)

This International Standard gives equivalent terms in English, French, Russian, German and Italian relating to spindles for ring-spinning and doubling machines.

NOTE - In addition to terms used in the three official languages (English, French and Russian), this International Standard gives the equivalent terms in the German and Italian languages; these are published under the responsibility of the member body for Germany, F.R. (DIN), for Switzerland (SNV) and for Italy (UNI). However, only the terms given in the official languages can be considered as ISO terms.

Figure 1 Ring spindle

NOTE - The figures are given as illustrative examples only.

Key

1	upper part of spindle
1.1	Spindle blade
1.2	l3lacIe point
1.3	Plug
1.4	Spring grip buttons
1.5	Whirl
1.6	Wharves
1.7	Brake flange
1.8	Undeiwinding flange
1.9	linderwinding sleeve
1.10	Holding clown catch
1.11	Spindle head 11cr suppressed ballon ring spinning I
2	Lower part of spindle
2.1	l3olster housing
2.2	Neck bearing
2.3	Foot bearing
2.4	Spindle damping
2.5	Spindle brake
2.6	Spindle fastening lnut and washerl
3	Spinning tube
4	Spindle rail
