CSN EN 61188-5-2 - Printed boards and printed board assemblies - Design and use - Part 5-2: Attachment (land/joint) considerations - Discrete components

CSN EN 61188-5-2

Printed boards and printed board assemblies - Design and use - Part 5-2: Attachment (land/joint) considerations - Discrete components

Format
Availability
Price and currency
English Hardcopy
In stock
103.53 USD
Category:359038
Released:2003
Number of Standard:CSN EN 61188-5-2
DESCRIPTION

EN 61188-5-2


EN 61188-5-2 Printed boards and printed board assemblies - Design and use - Part 5-2: Attachment (land/joint) considerations - Discrete components - Provides information on land pattern geometries used for the surface attachment of discrete electronic components. Provides the appropriate size, shape and tolerances of surface mount land patterns to ensure sufficient area for the appropriate solder fillet, and also allow for inspection, testing and rework of resulting solder joints.
