CSN EN 61188-5-5 - Printed boards and printed board assemblies - Design and use - Part 5 - 5: Attachment (land/joint) considerations - Components with gull-wing leads on four sides

CSN EN 61188-5-5

Printed boards and printed board assemblies - Design and use - Part 5 - 5: Attachment (land/joint) considerations - Components with gull-wing leads on four sides

Format
Availability
Price and currency
English Hardcopy
In stock
87.06 USD
Category:359038
Released:2007
Number of Standard:CSN EN 61188-5-5
DESCRIPTION

EN 61188-5-5


EN 61188-5-5 Printed boards and printed board assemblies - Design and use - Part 5 - 5: Attachment (land/joint) considerations - Components with gull-wing leads on four sides - IEC 61188-5-5:2007 provides information on land pattern geometries used for the surface attachment of electronic components with gull-wing leads on four sides. The intent of the information presented herein is to provide the appropriate size, shape and tolerances of surface mount land patterns to ensure sufficient area for the appropriate solder fillet, and also allow for inspection, testing and reworking of those solder joints. This publication is to be read in conjunction with IEC 61188-5-1 :2002.

Original English text of CSN EN Standard.
The price of the Standard included all amendments and correcturs.
