Released: 01.04.2020
CSN EN IEC 61169-64 - Radio frequency connectors - Part 64: Sectional specification - RF coaxial connectors with 0,8 mm inner diameter of outer conductor - Characteristic impedance 50 Ohm (type 0,8)

CSN EN IEC 61169-64

Radio frequency connectors - Part 64: Sectional specification - RF coaxial connectors with 0,8 mm inner diameter of outer conductor - Characteristic impedance 50 Ohm (type 0,8)

Format
Availability
Price and currency
English Hardcopy
In stock
76.67 USD
FREE Shipping
Number of Standard:CSN EN IEC 61169-64
Category:353811
Pages:32
Released:01.04.2020
Catalog number:509219
DESCRIPTION

CSN EN IEC 61169-64

CSN EN IEC 61169-64 This part of IEC 61169, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for IEC 61169 (all parts) coaxial connectors with 0,8 mm coupling. The connectors are used with cables with characteristic impedance 50 Ohm in an operating frequency range up to 145 GHz. The connectors are widely used in communications and measurements. It describes the interface dimensions for general purpose connectors with gauging information and the mandatory tests selected from IEC 61169-1, applicable to all detail specifications relative to type 0,8 connectors. This specification indicates the recommended performance characteristics to be considered when writing a DS and covers all tests schedules and inspection requirements.
Original English text of CSN EN Standard.
The price of the Standard included all amendments and correcturs.
