CSN EN ISO 6149-2 - Connections for hydraulic fluid power and general use - Ports and stud ends with ISO 261 metric threads and O-ring sealing - Part 2: Dimensions, design, test methods and requirements for heavy-duty (S series) stud ends (ISO 6149-2:2006)

CSN EN ISO 6149-2

Connections for hydraulic fluid power and general use - Ports and stud ends with ISO 261 metric threads and O-ring sealing - Part 2: Dimensions, design, test methods and requirements for heavy-duty (S series) stud ends (ISO 6149-2:2006)

Format
Availability
Price and currency
English Hardcopy
In stock
57.65 USD
Category:119380
Released:2006
Number of Standard:CSN EN ISO 6149-2
DESCRIPTION

EN ISO 6149-2


EN ISO 6149-2 Connections for hydraulic fluid power and general use - Ports and stud ends with ISO 261 metric threads and O-ring sealing - Part 2: Dimensions, design, test methods and requirements for heavy-duty (S series) stud ends (ISO 6149-2:2006) - ISO 6149-2:2006 specifies dimensions, performance requirements and test procedures for metric adjustable and non-adjustable heavy-duty (S series) stud ends and O-rings. Stud ends in accordance with ISO 6149-2:2006 may be used at working pressures up to 63 MPa (630 bar) for non-adjustable stud ends and 40 MPa (400 bar) for adjustable stud ends. The permissible working pressure depends upon the stud end size, materials, design, working conditions, application, etc.

Original English text of CSN EN Standard.
The price of the Standard included all amendments and correcturs.
