IEC 60191-6-13:2016
Mechanical standardization of semiconductor devices - Part 6-13: Design guideline of open-top-type sockets for Fine-pitch Ball Grid Array (FBGA) and Fine-pitch Land Grid Array (FLGA)
Normalisation mécanique des dispositifs à semiconducteurs - Partie 6-13: Guide de conception pour les supports sans couvercle pour les boîtiers matriciels à billes et à pas fins (FBGA) et les boîtiers matriciels à zone de contact plate et à pas fins (FLGA)
Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
140.56 USD
English/French - Bilingual Hardcopy
in stock
140.56 USD
| Standard number: | IEC 60191-6-13:2016 |
| Released: | 2016-09-27 |
| Language: | English/French - Bilingual |
DESCRIPTION
IEC 60191-6-13:2016
IEC 60191-6-13:2016 specifies a design guideline of open-top-type semiconductor sockets for Fine-pitch Ball Grid Array (FBGA) and Fine-pitch Land Grid Array (FLGA). In particular, this part of IEC 60191 establishes the outline drawings and dimensions of the open-top-type test and burn-in sockets applied to FBGA and FLGA. This edition includes the following significant technical changes with respect to the previous edition: a) BGA package nominal length and width have been newly expanded to 43 mm and 43 mm, respectively. Accordingly, six socket sizes have been added to the socket group numbers 1, 2 and 3, and twenty-two socket sizes have been added to the socket group number 4.
