Main page>IEC Standards>IEC 60191-6-2:2001 - Mechanical standardization of semiconductor devices - Part 6-2: General rules for the preparation of outline drawings of surface mounted semiconductor devices packages - Design guide for 1,50 mm, 1,27 mm and 1,00 mm pitch ball and column terminal packages
immediate downloadReleased: 2001-12-11
IEC 60191-6-2:2001 - Mechanical standardization of semiconductor devices - Part 6-2: General rules for the preparation of outline drawings of surface mounted semiconductor devices packages - Design guide for 1,50 mm, 1,27 mm and 1,00 mm pitch ball and column terminal packages

IEC 60191-6-2:2001

Mechanical standardization of semiconductor devices - Part 6-2: General rules for the preparation of outline drawings of surface mounted semiconductor devices packages - Design guide for 1,50 mm, 1,27 mm and 1,00 mm pitch ball and column terminal packages

Normalisation mécanique des dispositifs à semiconducteurs - Partie 6-2: Règles générales pour la préparation des dessins d'encombrement des dispositifs à semiconducteurs pour montage en surface - Guide de conception pour les boîtiers à broches en forme de billes et de colonnes, avec des pas de 1,50 mm, 1,27 mm et 1,00 mm

Format
Availability
Price and currency
English PDF
Immediate download
Printable
50.82 USD
English Hardcopy
in stock
50.82 USD
English/French - Bilingual PDF
Immediate download
Printable
50.82 USD
English/French - Bilingual Hardcopy
in stock
50.82 USD
View table of Contents
Standard number:IEC 60191-6-2:2001
Released:2001-12-11
Edition:1
ICS:31.080.01
Pages (English/French - Bilingual):21
ISBN (English/French - Bilingual):9782832205327
Pages (English):10
ISBN (English):2831860873
DESCRIPTION

IEC 60191-6-2:2001

IEC 60191-6-2:2001 covers the requirements for the preparation of drawings of integrated circuit outlines for the various ball terminal packages, e.g. ceramic ball grid array (C-BGA), plastic ball grid array (P-BGA), tape ball grid array (T-BGA) and others as well as column terminal packages, e.g. ceramic column grid array (C-CGA).
