IEC 60317-21:2013+AMD1:2019 CSV - Specifications for particular types of winding wires - Part 21: Solderable polyurethane enamelled round copper wire overcoated with polyamide, class 155

IEC 60317-21:2013+AMD1:2019 CSV

Specifications for particular types of winding wires - Part 21: Solderable polyurethane enamelled round copper wire overcoated with polyamide, class 155

Spécifications pour types particuliers de fils de bobinage - Partie 21: Fil brasable de section circulaire en cuivre émaillé avec polyuréthane et avec surcouche polyamide, classe 155

CURRENCY
LANGUAGE
English/French - Bilingual
Standard number:IEC 60317-21:2013+AMD1:2019 CSV
Released:2019-06-12
Language:English/French - Bilingual
DESCRIPTION

IEC 60317-21:2013+AMD1:2019 CSV

IEC 60317-21:2013+A1:2019 specifies the requirements of solderable enamelled round copper winding wire of class 155 with a dual coating. The underlying coating is based on polyurethane resin, which may be modified providing it retains the chemical identity of the original resin and meets all specified wire requirements. The superimposed coating is based on polyamide resin. NOTE - A modified resin is a resin that has undergone a chemical change, or contains one or more additives to enhance certain performance or application characteristics. The range of nominal conductor diameters covered by this standard is: - Grade 1: 0,050 mm up to and including 1,600 mm; - Grade 2: 0,050 mm up to and including 1,600 mm. The nominal conductor diameters are specified in Clause 4 of IEC 60317-0-1:2013. This third edition cancels and replaces the second edition published in 1990, Amendment 1:1997 and Amendment 2:1999. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: - new 3.2.2 containing general notes on winding wire, formerly a part of the scope; - revision to references to IEC 60317-0-1:2013 to clarify that their application is normative; - consolidation of 17.1 and 17.2 of the solderability requirements; - modification to Clause 19, Dielectric dissipation factor; - new Clause 23, Pin hole test. This consolidated version consists of the third edition (2013) and its amendment 1 (2019). Therefore, no need to order amendment in addition to this publication. Keywords: requirements of solderable enamelled round copper winding wire, class 155, dual coating
