IEC 60444-11:2026
Measurement of quartz crystal unit parameters - Part 11: Standard method for the determination of the load resonance frequency f<sub>L</sub> and the effective load capacitance C<sub>Leff</sub> using automatic network analyzer techniques and error correction
Mesure des paramètres des résonateurs à quartz - Partie 11: Méthode normalisée pour la détermination de la fréquence de résonance avec capacité de charge f<sub>L</sub> et de la capacité de charge effective C<sub>Leff</sub> à l'aide de techniques d'analyseur de réseau automatiques et de correction d'erreur
| Standard number: | IEC 60444-11:2026 |
| Released: | 2026-04-22 |
| Edition: | 2 |
| ICS: | 31.140 |
| Pages (English): | 27 |
| ISBN (English): | 9782832711996 |
IEC 60444-11:2026
IEC 60444-11:2026 defines the standard method of measuring load resonance frequency fL at the nominal value of CL, and the determination of the effective load capacitance CLeff at the nominal frequency for crystals with the figure of merit M > 4.
This edition includes the following significant technical changes with respect to the previous edition:
a) key content of withdrawn IEC TR 60444-4 is reproduced as Annex A;
b) some formulae in the first edition have been corrected.
