immediate downloadReleased: 2010-06-10
IEC 60512-21-1:2010
Connectors for electronic equipment - Tests and measurements - Part 21-1: RF resistance tests - Test 21a: RF shunt resistance
Connecteurs pour équipements électroniques - Essais et mesures - Partie 21-1: Essais de résistance aux fréquences radioélectriques - Essai 21a: Résistance parallèle aux fréquences radioélectriques
IEC 60512-21-1:2010 when required by the detail specification, is used for testing connectors within the scope of technical committee 48. It may also be used for similar devices when specified in a detail specification. The object of this standard is to detail a standard test method to determine the value of RF shunt resistance which degrades the quality factor of an L/C circuit when a connector is connected in parallel. This value is expressed in terms of a parallel damping resistance.
