IEC 60534-8-3:2010 - Industrial-process control valves - Part 8-3: Noise considerations - Control valve aerodynamic noise prediction method

IEC 60534-8-3:2010

Industrial-process control valves - Part 8-3: Noise considerations - Control valve aerodynamic noise prediction method

Vannes de régulation des processus industriels - Partie 8-3: Considérations sur le bruit - Méthode de prédiction du bruit aérodynamique des vannes de régulation

Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
330.00 USD
English/French - Bilingual Hardcopy
in stock
330.00 USD
Standard number:IEC 60534-8-3:2010
Released:2010-11-29
Language:English/French - Bilingual
DESCRIPTION

IEC 60534-8-3:2010

IEC 60534-8-3:2010 establishes a theoretical method to predict the external sound-pressure level generated in a control valve and within adjacent pipe expanders by the flow of compressible fluids. This method considers only single-phase dry gases and vapours and is based on the perfect gas laws. It is assumed that the downstream piping is straight for a length of at least 2 m from the point where the noise measurement is made. The method is applicable to the following single-stage valves: - globe (straight pattern and angle pattern), - butterfly, - rotary plug (eccentric, spherical), - ball, and - valves with cage trims. Specifically excluded are the full bore ball valves where the product FpC exceeds 50 % of the rated flow coefficient. This third edition cancels and replaces the second edition published in 2000. This edition constitutes a technical revision. The significant technical changes with respect to the previous edition are as follows: - predicting noise as a function of frequency; - using laboratory data to determine the acoustical efficiency factor.
