download between 0-24 hoursReleased: 2010-06-28
IEC 60603-7-71:2010
Connectors for electronic equipment - Part 7-71: Detail specification for 8-way, shielded, free and fixed connectors, for data transmission with frequencies up to 1 000 MHz
Connecteurs pour équipements électroniques - Partie 7-71: Spécification particulière pour les fiches et les embases blindées à 8 voies pour la transmission de données à des fréquences jusqu'à 1 000 MHz
Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
140.56 USD
English/French - Bilingual Hardcopy
in stock
140.56 USD
| Standard number: | IEC 60603-7-71:2010 |
| Released: | 2010-06-28 |
| Language: | English/French - Bilingual |
DESCRIPTION
IEC 60603-7-71:2010
IEC 60603-7-71:2010 covers 8-way, shielded, free and fixed connectors, references dimensional, mechanical, electrical and environmental characteristics and tests in IEC 60603-7, and specifies electrical transmission requirements, including power sum alien (exogenous) crosstalk, for frequencies up to 1 000 MHz. These connectors are typically used as category 7A connectors in class FA cabling systems specified in ISO/IEC 11801. These connectors are intermateable and interoperable with other IEC 60603-7 series connectors as defined in Clause 2 of IEC 60603-7-1 and IEC 60603-7-7. These connectors are backward compatible with other IEC 60603-7 series connectors.
