IEC 60603-7-81:2015
Connectors for electronic equipment - Part 7-81: Detail specification for 8-way, shielded, free and fixed connectors, for data transmissions with frequencies up to 2 000 MHz
Connecteurs pour équipements électroniques - Partie 7-81: Spécification particulière pour les fiches et les embases blindées à 8 voies pour la transmission de données à des fréquences jusqu'à 2 000 MHz
| Standard number: | IEC 60603-7-81:2015 |
| Released: | 2015-12-16 |
| Language: | English/French - Bilingual |
IEC 60603-7-81:2015
IEC 60603-7-81:2015 Covers 8-way, shielded, free and fixed connectors, references dimensional, mechanical, electrical and environmental characteristics and tests in IEC 60603-7, and specifies electrical transmission requirements, including power sum alien (exogenous) crosstalk, for frequencies up to 2 000 MHz. These connectors are typically used as "category 8.1" connectors in "class I" cabling systems specified in ISO/IEC 11801. These connectors are intermateable and interoperable with other IEC 60603-7 series connectors as defined in Clause 2 of IEC 60603-7. These connectors are backward compatible with other IEC 60603-7 series connectors, except IEC 60603-7-7 and IEC 60603-7-71 connectors. Key words: Connectors, Shielded, Free and Fixed Connectors The contents of the corrigendum of June 2017 have been included in this copy.
