IEC 60917-2-3:2006
Modular order for the development of mechanical structures for electronic equipment practices - Part 2-3: Sectional specification - Interface co-ordination dimensions for the 25 mm equipment practice - Extended detail specification - Dimensions for subracks, chassis, backplanes, front panels and plug-in units
Ordre modulaire pour le développement des structures mécaniques pour les infrastructures électroniques - Partie 2-3: Spécification intermédiaire - Dimensions de coordination pour les interfaces des infrastructures au pas de 25 mm - Spécification particulière étendue - Dimensions pour bacs, châssis, fonds de paniers, faces avant et unités enfichables
| Standard number: | IEC 60917-2-3:2006 |
| Released: | 2006-05-09 |
| Edition: | 1 |
| ICS: | 31.240 |
| Pages (English/French - Bilingual): | 71 |
| ISBN (English/French - Bilingual): | 9782832208854 |
| Pages (English): | 35 |
| ISBN (English): | 2831886228 |
IEC 60917-2-3:2006
IEC 60917-2-3:2006 Provides additional dimensions for a modular range of subracks and associated plug-in units based on IEC 60917-2-2. A typical subrack consists of a frame design with mounting dimensions for installation into racks or cabinets in accordance with IEC 60917-2-1. The aperture dimensions of a subrack are specified in order to meet the mounting dimensions of front plug-in units. This part of IEC 60917 comprises additional dimensions for subracks and subrack associated plug-in units with injector/extractor handle, dimensions for basic electromagnetic shielding provisions, dimensions of the key/coding system for subrack and plug-in units, dimensions of the alignment pin for front panel and plug-in unit, dimensions of electrostatic discharge provisions and dimensions of rear-mounted plug-in units. This bilingual version (2013-06) corresponds to the monolingual English version, published in 2006-05. Key words: subrack, plug in units, chassis
