IEC 61076-3-104:2017 - Connectors for electrical and electronic equipment - Product requirements - Part 3-104: Detail specification for 8-way, shielded free and fixed connectors for data transmissions with frequencies up to 2 000 MHz

IEC 61076-3-104:2017

Connectors for electrical and electronic equipment - Product requirements - Part 3-104: Detail specification for 8-way, shielded free and fixed connectors for data transmissions with frequencies up to 2 000 MHz

Connecteurs pour équipements électriques et électroniques - Exigences de produit - Partie 3-104: Spécification particulière pour les fiches et les embases écrantées à 8 voies pour la transmission de données à des fréquences jusqu'à 2 000 MHz

CURRENCY
LANGUAGE
Standard number:IEC 61076-3-104:2017
Released:2017-05-22
Language:English
DESCRIPTION

IEC 61076-3-104:2017

IEC 61076-3-104:2017 establishes uniform specifications, type testing requirements for 8 way, shielded free and fixed connectors for data transmissions with frequencies up to 2 000 MHz, and used as category 7A connectors in class FA cabling systems specified in ISO/IEC 11801-1. It contains all test methods and sequences, severity and preferred values for dimensions and characteristics. This third edition of IEC 61076-3-104 cancels and replaces the second edition, published in 2006, and constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: - the title has been changed to incorporate transmissions with frequencies up to 2 000 MHz; - the drawings of some styles have been corrected for clarification; - Figures 23 and 24 have been updated; - Figure 3 has been updated to include reference dimensions and dimensional format changes; - the dimensions of Figure 7 have been updated; - the type designation and ordering information has been removed for consistency with the most updated sectional specification; - the test schedule was updated to include appropriate IEC 60512 Test Nos; - the electrical performance requirements have been revised for 2 GHz level and interchangeability information has been added for performance categories.
