IEC 61169-48:2014 - Radio-frequency connectors - Part 48: Sectional specification for series BMP R.F. coaxial connectors

IEC 61169-48:2014

Radio-frequency connectors - Part 48: Sectional specification for series BMP R.F. coaxial connectors

Connecteurs pour fréquences radioélectriques - Partie 48: Spécification intermédiaire relatives aux connecteurs coaxiaux R.F. série BMP

CURRENCY
LANGUAGE
English/French - Bilingual
Standard number:IEC 61169-48:2014
Released:2014-10-23
Language:English/French - Bilingual
DESCRIPTION

IEC 61169-48:2014

IEC 61169-48:2014, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for series BMP RF coaxial connectors with blind mating, typically for use in 50 Ohms board to board connection. They may also be used with RF cables or micro-strips in microwave, telecommunication, wireless and other fields. Their operating frequency limit is up to 6 GHz. It describes the interface dimensions with gauging information, electrical and mechanical performance including the mandatory tests selected from IEC 61169-1:2013 applicable to all DS relating to type BMP connectors. This specification indicates the recommended performance characteristics to be considered when writing a DS and covers test schedules and inspection requirements.
