Homepage>IEC Standards>IEC 61169-54:2021 - Radio frequency connectors - Part 54: Sectional specification for coaxial connectors with 10 mm inner diameter of outer conductor, nominal characteristic impedance 50 Ω, Series 4,3-10
Sponsored link
download between 0-24 hoursReleased: 2021-08-27

IEC 61169-54:2021

Radio frequency connectors - Part 54: Sectional specification for coaxial connectors with 10 mm inner diameter of outer conductor, nominal characteristic impedance 50 Ω, Series 4,3-10

Connecteurs pour fréquences radioélectriques - Partie 54: Spécification intermédiaire relative aux connecteurs coaxiaux avec diamètre intérieur du conducteur extérieur de 10 mm, impédance caractéristique nominale de 50 Ω, série 4,3-10

Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
265.29 USD
English/French - Bilingual Hardcopy
in stock
265.29 USD
Standard number:IEC 61169-54:2021
Released:2021-08-27
Language:English/French - Bilingual
DESCRIPTION

IEC 61169-54:2021

IEC 61169-54:2021 is available as IEC 61169-54:2021 RLV which contains the International Standard and its Redline version, showing all changes of the technical content compared to the previous edition.IEC 61169-54:2021 provides information and rules for the preparation of detail specifications (DS) for coaxial connectors with 10 mm inner diameter of outer conductor, characteristic impedance 50 Ω, series 4,3-10 with screw type, hand screw type or quick-lock type coupling, for an upper operating frequency limit of 6 GHz, for use in wireless telecommunication and wireless network applications in conjunction with appropriate transmission line types for these applications. This specification indicates the recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H. This second edition cancels and replaces the first edition published in 2016. This edition includes the following significant technical changes with respect to the previous edition: - Table 8: some values changed.
