Fibre optic interconnecting devices and passive components - Basic test and measurement procedures - Part 3-30: Examinations and measurements - Endface geometry of rectangular ferrule
Dispositifs d'interconnexion et composants passifs fibroniques - Procédures fondamentales d'essais et de mesures - Partie 3-30: Examens et mesures - Géométrie de la face terminale de la ferrule rectangulaire
|Standard number:||IEC 61300-3-30:2020|
|Language:||English/French - Bilingual|
IEC 61300-3-30:2020 is available as IEC 61300-3-30:2020 RLV which contains the International Standard and its Redline version, showing all changes of the technical content compared to the previous edition. IEC 61300-3-30:2020 describes a method of measuring the end face geometry of rectangular multifibre ferrules having an IEC defined optical interface. The primary attributes are fibre position relative to the end face, either withdrawal or protrusion, end face angle relative to the guide pin bores, fibre tip radii and core dip for multimode fibres. This second edition cancels and replaces the first edition published in 2003. This edition constitutes a technical revision.This edition includes the following significant technical changes with respect to the previous edition: - measurement of the individual fibre tip radii; - introduction of the geometry limit (GL) metric; - introduction of the minus coplanarity metric; - new method for measuring the core dips; - all measurement regions are now identical for MM and SM fibres; - the ferrule surface angle sign convention has been changed.
