Electric vehicle wireless power transfer (WPT) systems - Part 3: Specific requirements for magnetic field wireless power transfer systems
Systèmes de transfert de puissance sans fil (WPT) pour véhicules électriques – Partie 3: Exigences spécifiques pour les systèmes de transfert de puissance sans fil par champ magnétique
|Standard number:||IEC 61980-3:2022|
|Language:||English/French - Bilingual|
IEC 61980-3:2022 applies to the off-board supply equipment for wireless power transfer via magnetic field (MF-WPT) to electric road vehicles for purposes of supplying electric energy to the RESS (rechargeable energy storage system) and/or other on-board electrical systems. The MF-WPT system operates at standard supply voltage ratings per IEC 60038 up to 1 000 V AC and up to 1 500 V DC from the supply network. The power transfer takes place while the electric vehicle (EV) is stationary. Off-board supply equipment fulfilling the requirements in this document are intended to operate with EV devices fulfilling the requirements described in ISO 19363. The aspects covered in this document include – the characteristics and operating conditions, – the required level of electrical safety, – requirements for basic communication for safety and process matters if required by a MF WPT system, – requirements for positioning to assure efficient and safe MF-WPT power transfer, and – specific EMC requirements for MF-WPT systems. The following aspects are under consideration for future documents: – requirements for MF-WPT systems for two- and three-wheel vehicles, – requirements for MF-WPT systems supplying power to EVs in motion, – requirements for bidirectional power transfer, – requirements for flush mounted primary device, – requirements for MF-WPT systems for heavy duty vehicle, and – requirements for MF-WPT systems with inputs greater than 11,1 kVA. This document does not apply to – safety aspects related to maintenance, and – trolley buses, rail vehicles and vehicles designed primarily for use off-road. IEC 61980-3:2022 is to be used in conjunction with IEC 61980-1:2020.
