IEC 63295:2022
Specification for WB series glass beads with 50 Ω impedance for RF connectors
Spécification pour perles en verre de série WB à impédance de 50 Ω pour connecteurs RF
Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
140.56 USD
English/French - Bilingual Hardcopy
in stock
140.56 USD
| Standard number: | IEC 63295:2022 |
| Released: | 2022-02-24 |
| Language: | English/French - Bilingual |
DESCRIPTION
IEC 63295:2022
IEC 63295:2022 provides the requirements for WB series glass beads with 50 Ω impedance for RF connectors, including, among other, the structure dimensions, IEC type designation, rating and characteristics, and quality assessment. These glass beads are used for the adaption of coaxial systems to microstrip circuits used extensively in microwave communication systems such as TR modules, power modules, integrated circuits where hermetic seal is required.
