PRICES include / exclude VAT
Released: 01.03.2018
IPC-2292 - Standard Only
Design Standard for Printed Electronics on Flexible Substrates
Format
Availability
Price and currency
English Secure PDF
Immediate download
Non-printable
198.00 USD
English Hardcopy
10-14 days
297.00 USD
View table of Contents
| Standard Number: | IPC-2292 - Standard Only |
| DOD Adopted: | No |
| ANSI Approved: | No |
| Released: | 01.03.2018 |
| ISBN (English): | 978-1-61193-343-7 |
| Pages (English): | 72 |
DESCRIPTION
Superseded by IPC-2292-Revision A
IPC-2292 standard establishes specific requirements for the design of printed electronic applications and their forms of component mounting and interconnecting structures on flexible substrates. Flexible substrates, as pertaining to IPC-2292 standard, are materials or devices which have some amount of flexibility or bendability (not rigid) but are not considered to be stretchable (e.g., fabrics, textiles, stretchable polymers, etc.).
IPC-2292 standard also defines three Standard Printed Electronic Designs (SPEDs) and includes an appendix with fabrication and design
