IPC-7525 - Revision B
Stencil Design Guidelines
Format
Availability
Price and currency
Chinese Secure PDF
Immediate download
Non-printable
111.00 USD
Chinese Hardcopy
10-14 days
166.51 USD
English Secure PDF
Immediate download
Non-printable
111.00 USD
English Hardcopy
10-14 days
166.51 USD
German Secure PDF
Immediate download
Non-printable
155.00 USD
German Hardcopy
10-14 days
232.51 USD
View table of Contents
| Standard Number: | IPC-7525 - Revision B |
| DOD Adopted: | No |
| ANSI Approved: | No |
| Revision: | B |
| Released: | 24.10.2011 |
| ISBN (English): | 978-1-61193-020-7 |
| Pages (English): | 14 |
| ISBN (Chinese): | 978-1-61193-125-9 |
| Pages (Chinese): | 14 |
| ISBN (German): | 978-1-61193-085-6 |
| Pages (German): | 36 |
DESCRIPTION
Superseded by IPC-7525 - Revision C
This document provides guidelines for the design and fabrication of stencils for solder paste and surface mount adhesive with discussion on through-hole and mixed technology. This includes differences for tin lead and lead-free solder paste, overprint, two-print and step stencil designs. A sample order form and user inspection checklist are also included.
