ISO 20170:2019

This document describes principles and tools to control a manufacturing process in accordance with a GPS specification. For this purpose a set of one or more complementary, independent characteristics (size, form, orientation, and location characteristics independent to each other) that correlate to the manufacturing process parameters and to the manufacturing process coordinate system established from the manufacturing datum system are used. This document describes the concept of decomposition of the macro-geometrical part of the GPS specification. It does not cover the micro-geometry, i.e. surface texture. The objective of the decomposition presented in this document is to define correction values for manufacturing control or to perform a statistical analysis of the process.
