UNE EN 17290:2022 - Non-destructive testing - Ultrasonic testing - Examination for loss of thickness due to erosion and/or corrosion using the TOFD technique

UNE EN 17290:2022

Non-destructive testing - Ultrasonic testing - Examination for loss of thickness due to erosion and/or corrosion using the TOFD technique

Ensayos no destructivos. Ensayo por ultrasonidos. Examen de la pérdida de espesor debido a la erosión y/o corrosión usando la técnica TOFD.

Format
Availability
Price and currency
English PDF
Immediate download
Printable
95.76 USD
English Hardcopy
In stock
95.76 USD
Spanish PDF
Immediate download
Printable
95.76 USD
Spanish Hardcopy
In stock
95.76 USD
Standard number:UNE EN 17290:2022
Pages:25
Released:2022-10-19
Status:Standard
Pages (Spanish):26
DESCRIPTION

UNE EN 17290:2022

This document specifies the application of the time-of-flight diffraction (TOFD) technique in testing of metals for quantifying loss of thickness due to erosion and/or corrosion. This document applies to all types of corrosion or erosion damage, particularly those defined in ISO 16809. This test applies to unalloyed or low-alloyed steel materials. It applies to components with a nominal thickness e" 6 mm. For smaller thicknesses feasibility tests will be performed to validate the technique. For other materials, feasibility tests are essential too. The TOFD technique can be used here as a stand-alone technique or in combination with other non-destructive testing techniques, during manufacturing and for testing in-service, in order to detect material loss caused by erosion and/or corrosion. This technique is based on analysis of TOFD images established using reflected and/or diffracted ultrasonic signals. This document does not specify acceptance levels.
