UNE EN 3660-066:2017
Aerospace series - Cable outlet accessories for circular and rectangular electrical and optical connectors - Part 066: Cable outlet, style K, 90°, for heat shrinkable boot, shielded, sealed - Product standard (Endorsed by Asociación Española de Normalización in October of 2017.)
Material aeroespacial. Accesorios de cable de toma de corriente para conectores circulares y rectangulares, eléctricos y ópticos. Parte 066: Toma de corriente para cable, estilo K, 90º, para piezas moldeadas termorretráctiles, blindada, soldada para EN 2997 y EN 3646. Norma de producto. (Ratificada por la Asociación Española de Normalización en octubre de 2017.)
| Standard number: | UNE EN 3660-066:2017 |
| Pages: | 20 |
| Released: | 2017-10-01 |
| Status: | Standard |
UNE EN 3660-066:2017
This European Standard defines a range of cable outlets, style K, 90°, shielded, sealed for heat shrinkable boot, for use with memory metal rings under the following conditions. The mating connectors are listed in EN 3660-002. NOTE Class N in EN 3660-001 cross refers to Class F in EN 3660-066. Temperature range, Class N(F) : " 65 °C to 200 °C (See note above) Class K : " 65 °C to 200 °C Class W : " 65 °C to 175 °C Class T : " 65 °C to 175 °C (Nickel PTFE plating) Class Z : " 65 °C to 175 °C (Zinc nickel plating) Associated electrical accessories : EN 3660-034 memory metal rings (for shield termination backshells). These cable outlets are designed for termination of overall shielding braid or individual cable shields. They accommodate/permit the termination of heat shrinkable boots.
