UNE EN 4838-005:2019
Aerospace series - Arc fault circuit breakers, single-pole, temperature compensated, rated current 3 A to 25 A - 115 V a.c. 400 Hz Constant Frequency - Part 005: With polarized signal contact - Product standard (Endorsed by Asociación Española de Normalización in August of 2019.)
Material aeroespacial. Disyuntores unipolares, detección de arco, compensados en temperatura, corriente nominal 3 A a 25 A - 115 V a.c. 400 Hz frecuencia constante. Parte 005: Con contacto de señalización polarizado. Norma de producto (Ratificada por la Asociación Española de Normalización en agosto de 2019.)
| Standard number: | UNE EN 4838-005:2019 |
| Pages: | 14 |
| Released: | 2019-08-01 |
| Status: | Standard |
UNE EN 4838-005:2019
This European Standard specifies the required characteristics for single-pole, arc fault circuit breakers rated currents from 3 A to 25 A, switching capacity 65 In, for use in aircraft electrical systems. Their operating temperatures are between " 40 °C to 85 °C at a maximum altitude of Z = 15 000 m. The thermal protection is temperature compensated and operates between " 55 °C and 125 °C. These circuit breaker are operated by a push-pull type single pushbutton (actuator), with delayed action "trip-free" tripping. They will continue to function up to the short-circuit current.
