>UNE standards>UNE EN 50068:2018 - High-Voltage Switchgear and Controlgear - Gas-filled wrought steel enclosures (Endorsed by Asociación Española de Normalización in January of 2019.)
in stockReleased: 2019-01-01
UNE EN 50068:2018 - High-Voltage Switchgear and Controlgear - Gas-filled wrought steel enclosures (Endorsed by Asociación Española de Normalización in January of 2019.)

UNE EN 50068:2018

High-Voltage Switchgear and Controlgear - Gas-filled wrought steel enclosures (Endorsed by Asociación Española de Normalización in January of 2019.)

Aparamenta de alta tensión. Envolventes de acero soldado bajo gas a presión. (Ratificada por la Asociación Española de Normalización en enero de 2019.)

Format
Availability
Price and currency
English PDF
Immediate download
Printable
97.06 USD
English Hardcopy
In stock
97.06 USD
Standard number:UNE EN 50068:2018
Pages:29
Released:2019-01-01
Status:Standard
DESCRIPTION

UNE EN 50068:2018

This European Standard applies to welded wrought steel enclosures pressurised with dry air, inert gases, for example sulphur hexafluoride or nitrogen or a mixture of such gases, used in indoor and outdoor installations of high-voltage switchgear and controlgear with rated voltages above 1kV, where the gas is used principally for its dielectric and/or arc-quenching properties with rated voltages. above 1 kV and up to and including 52 kV and with gas-filled compartments with design pressure higher than 300 kPa relative pressure (gauge); and with rated voltage above 52 kV. The enclosures comprise parts of electrical equipment not necessarily limited to the following examples: circuit-breakers; switch-disconnectors; disconnectors; earthing switches; current transformers; voltage transformers; surge arrestors; busbars and connections; etc. The scope also covers enclosures of pressurized components such as the centre chamber of live tank switchgear, gas-insulated current transformers, etc.
