Main page>UNE standards>UNE EN IEC 61076-3-124:2019 - Connectors for electrical and electronic equipment - Product requirements - Part 3-124: Rectangular connectors - Detail specification for 10-way, shielded, free and fixed connectors for I/O and data transmission with frequencies up to 500 MHz (Endorsed by Asociación Española de Normalización in June of 2019.)
in stockReleased: 2019-06-01
UNE EN IEC 61076-3-124:2019 - Connectors for electrical and electronic equipment - Product requirements - Part 3-124: Rectangular connectors - Detail specification for 10-way, shielded, free and fixed connectors for I/O and data transmission with frequencies up to 500 MHz (Endorsed by Asociación Española de Normalización in June of 2019.)

UNE EN IEC 61076-3-124:2019

Connectors for electrical and electronic equipment - Product requirements - Part 3-124: Rectangular connectors - Detail specification for 10-way, shielded, free and fixed connectors for I/O and data transmission with frequencies up to 500 MHz (Endorsed by Asociación Española de Normalización in June of 2019.)

Conectores para equipos electrónicos. Requisitos del producto. Parte 3-124: Conectores rectangulares. Especificación particular para conectores rectangulares apantallados de 10 vías, libres y fijos para entrada/salida y capacidad de transmisión de datos con frecuencias de hasta 500 MHz. (Ratificada por la Asociación Española de Normalización en junio de 2019.)

Format
Availability
Price and currency
English PDF
Immediate download
Printable
122.94 USD
English Hardcopy
In stock
122.94 USD
Standard number:UNE EN IEC 61076-3-124:2019
Pages:54
Released:2019-06-01
Status:Standard
DESCRIPTION

UNE EN IEC 61076-3-124:2019

This part of IEC 61076 covers 10-way shielded free and fixed rectangular connectors for data transmission with frequencies up to 500 MHz and specifies the common dimensions, mechanical, electrical and transmission characteristics and environmental requirements as well as test specifications respectively. Connectors covered in this standard are provided in three codings that differ only for the position of the polarization key and keyway, in view of their differently intended use: " Connectors type A and C are intended for 10/100 Mbit/s as well as for 1/ 2,5 / 5 /10 Gbit/s Ethernet communication. " Connectors type B are intended for all other non Ethernet applications like signalling, serial or other industrial bus communication systems. A-coding: The 45° cut corner used as polarization key and keyway system is located on the lower left corner of the male fixed connector (viewed from mating face). (Figures 5a, 5b) B-coding: The 45° cut corner is located on the upper left corner of the male fixed connector (Figures 5c, 5d) C-coding: There are two 45° corners located at the upper left and lower left corner (Figures 5e, 5f) Subsequently within this document the three codings, A, B, and C will be designated as Type A , Type B and Type C .
