Replacement This document of the IEC 61558 series deals with safety of separating transformers for general applications and power supply units incorporating separating transformers for general applications. Transformers incorporating electronic circuits are also covered by this standard. NOTE 1 Safety includes electrical, thermal and mechanical aspects. Unless otherwise specified, from here onward, the term transformer covers separating transformers for general applications and power supply units incorporating separating transformers for general applications. For power supply units (linear) IEC 61558-2-1 is applicable. For switch mode power supply units, IEC 61558-2-16 is applicable. IEC 61558-2-1 does not apply to transformers covered by IEC 60076-11. IEC 61558-2-1 is applicable to stationary or portable, single-phase or polyphase, air-cooled (natural or forced) independent or associated dry- type transformers. The windings may be encapsulated or non-encapsulated. The rated supply voltage does not exceed 1 000 V AC and the rated supply frequency and the internal operating frequencies do not exceed 500 Hz. The rated output does not exceed: 1 kVA for single-phase separating transformers and single-phase power supply units incorporating separating transformers; 5 kVA for poly-phase separating transformers and poly-phase power supply units incorporating separating transformers. IEC 61558-2-1 is applicable to separating transformers without limitation of the rated output subject to an agreement between the purchaser and the manufacturer. NOTE 2 Transformers intended to supply distribution networks are not included in the scope. The no-load output voltage or the rated output voltage does not exceed 1 000 V AC or 1 415 V ripple-free DC. For independent separating transformers and independent power supply units, the no-load output voltage and / or the rated output voltage is not less than 50 V AC., or 120 V ripple-free DC. IEC 61558-2-1 is not applicable to external circuits and their components intended to be connected to the input terminals and output terminals of the transformers. NOTE 3 Separating transformers covered by IEC 61558-2-1 are only used in applications where double or reinforced insulation between circuits is not required by the installation rules or by the end product standard. NOTE 4 Normally, the separating transformers are intended to be used with equipment to provide voltages different from the supply voltage for the functional requirements of the equipment. The protection against electric shock may be provided or completed by other features of the equipment, such as the body. Parts of output circuits may be connected to the input circuits or to protective earthing. Attention is drawn to the following: for separating transformers and power supply units incorporating separating transformers intended to be used in vehicles, on board ships, and aircraft, additional requirements (from other applicable standards, national rules, etc.) may be necessary; measures to protect the enclosure and the components inside the enclosure against external influences such as fungus, vermin , termites, solar-radiation, and icing should also be considered; the different conditions for transportation, storage, and operation of the separating transformers and power supply units incorporating separating transformers should also be considered; additional requirements in accordance with other appropriate standards and national rules may be applicable to separating transformers and power supply units incorporating separating transformers intended for use in special environments, such as tropical environment. Future technological development of separating transformers and power supply units incorporating separating transformers may necessitate a need to increase the upper limit of the frequencies, until then IEC 61558-2-1 may be used as a guidance document. This group safety publication is primarily intended to be used as a product safety standard for the products mentioned in the scope, but shall also be used by technical committees in the preparation of standards for products similar to those mentioned in the scope of this standard, in accordance with the principles laid down in IEC Guide 104 and ISO/IEC Guide 51. One of the responsibilities of a technical committee is, wherever applicable, to make use of basic safety publications and/or group safety publications in the preparation of its publications.
