UNE EN ISO 13715:2019
Technical product documentation - Edges of undefined shape - Indication and dimensioning (ISO 13715:2017) (Endorsed by Asociación Española de Normalización in November of 2019.)
Documentación técnica de los productos. Bordes de forma indefinida. Indicación y dimensionamiento (ISO 13715:2017) (Ratificada por la Asociación Española de Normalización en noviembre de 2019.)
Format
Availability
Price and currency
English PDF
Immediate download
Printable
104.82 USD
English Hardcopy
In stock
104.82 USD
| Standard number: | UNE EN ISO 13715:2019 |
| Pages: | 33 |
| Released: | 2019-11-01 |
| Status: | Standard |
DESCRIPTION
UNE EN ISO 13715:2019
This document specifies rules for the indication and dimensioning of undefined edges in technical product and dimensions. The proportions and dimensions of the graphical symbols to be used are also specified. In cases where the geometrically defined shape of an edge (for example, 1 × 45°) is required, the general dimensioning principles given in ISO 129-1 apply.
