UNE EN ISO 6149-1:2023
Connections for hydraulic fluid power and general use - Ports and stud ends with ISO 261 metric threads and O-ring sealing - Part 1: Ports with truncated housing for O-ring seal (ISO 6149-1:2022)
Conexiones para transmisiones hidráulicas y aplicaciones generales. Orificios y extremos macho con roscas métricas ISO 261 y junta de estanquidad tórica. Parte 1: Orificios con alojamiento troncocónico para junta tórica. (ISO 6149-1:2022).
| Standard number: | UNE EN ISO 6149-1:2023 |
| Pages: | 15 |
| Released: | 2023-01-18 |
| Status: | Standard |
UNE EN ISO 6149-1:2023
This document specifies dimensions for metric ports for use with the adjustable and non-adjustable stud ends as described in ISO 6149-2 and ISO 6149-3. Ports in accordance with this document can be used at working pressures up to 63 MPa (630 bar1)) for non-adjustable stud ends and 40 MPa (400 bar) for adjustable stud ends. The permissible working pressure depends upon port size, materials, design, working conditions, application, etc. See ISO 6149-2 and ISO 6149-3 for pressure ratings. NOTE The Introduction of this document gives recommendations for ports and stud ends to be used for new designs in hydraulic fluid power applications.
