CSN EN 60191-6-18 - Mechanical standardization of semiconductor devices - Part 6-18: General rules for the preparation of outline drawings of surface mounted semiconductor device packages - Design guide for ball grid array (BGA)

CSN EN 60191-6-18

Mechanical standardization of semiconductor devices - Part 6-18: General rules for the preparation of outline drawings of surface mounted semiconductor device packages - Design guide for ball grid array (BGA)

Format
Availability
Price and currency
English Hardcopy
In stock
64.71 USD
Category:358791
Released:2010
Number of Standard:CSN EN 60191-6-18
DESCRIPTION

EN 60191-6-18


EN 60191-6-18 Mechanical standardization of semiconductor devices - Part 6-18: General rules for the preparation of outline drawings of surface mounted semiconductor device packages - Design guide for ball grid array (BGA) - IEC 60191-6-18:2010 provides standard outline drawings, dimensions, and recommended variations for all square ball grid array packages (BGA), whose terminal pitch is 1 mm or larger. This standard cancels and replaces IEC/PAS 60191-6-18 published in 2008. This first edition constitutes a technical revision. The contents of the corrigenda of May 2010 and July 2010 have been included in this copy.

Original English text of CSN EN Standard.
The price of the Standard included all amendments and correcturs.
