CSN EN 60191-6 ed. 2 - Mechanical standardization of semiconductor devices - Part 6: General rules for the preparation of outline drawings of surface mounted semiconductor device packages

CSN EN 60191-6 ed. 2

Mechanical standardization of semiconductor devices - Part 6: General rules for the preparation of outline drawings of surface mounted semiconductor device packages

Format
Availability
Price and currency
English Hardcopy
In stock
87.06 USD
Category:358791
Released:2009
Number of Standard:CSN EN 60191-6 ed. 2
DESCRIPTION

EN 60191-6 ed. 2


EN 60191-6 ed. 2 Mechanical standardization of semiconductor devices - Part 6: General rules for the preparation of outline drawings of surface mounted semiconductor device packages - IEC 60191-6:2009 gives general rules for the preparation of outline drawings of surface-mounted semiconductor devices. It supplements IEC 60191-1 and IEC 60191-3. It covers all surface-mounted devices discrete semiconductors with lead count of greater or equal to 8, as well as integrated circuits classified as form E in Clause 3 of IEC 60191-4. This third edition of IEC 60191-6 cancels and replaces the second edition, published in 2004 and constitutes a technical revision. This edition includes the following significant changes with respect to the previous edition: a) scope is modified to cover all surface-mounted devices discrete semiconductors with lead count of greater or equal to 8; b) editorial modifications on several pages; and c) technical revision to ball grid array package (BGA) especially its geometrical drawing format. (two types of BGA would unify as one type as a result of revising drawing format.

Original English text of CSN EN Standard.
The price of the Standard included all amendments and correcturs.
