download between 0-24 hoursReleased: 2019
ISO 6480:2019
ISO 6480:2019-Test conditions for horizontal internal type broaching machines-Testing of accuracy
Format
Availability
Price and currency
English PDF
Immediate download
172.22 USD
English Hardcopy
In stock
172.22 USD
French PDF
Immediate download
172.22 USD
French Hardcopy
In stock
172.22 USD
Standard´s number: | ISO 6480:2019 |
Pages: | 18 |
Edition: | 3 |
Released: | 2019 |
DESCRIPTION
ISO 6480:2019
This document specifies, with reference to ISO 230‑1, the geometric tests on internal type broaching machines with horizontal Z-axis providing the main cutting motion. It also specifies the applicable tolerances corresponding to the tests mentioned above for normal-accuracy horizontal internal type broaching machines. This document explains concepts or configurations and common features of horizontal internal type broaching machines. It also provides related terminology and designation of axes. It deals only with the verification of the accuracy of the machine. It does not apply to the operational testing of the machine (e.g. vibration, abnormal noise, stick-slip motion of components), nor to machine characteristics (e.g. speeds, feeds) as such checks are generally carried out before testing the accuracy.
