IEC 61169-47:2015
Radio-frequency connectors - Part 47: Sectional specification for radio-frequency coaxial connectors with clamp coupling, typically for use in 75 Ω cable networks (type F-Quick)
Connecteurs pour fréquences radioélectriques - Partie 47: Spécification intermédiaire relative aux connecteurs coaxiaux pour fréquences radioélectriques avec couplage par bride, spécifiquement utilisés dans les réseaux câblés 75 Ω (type F-Quick)
| Standard number: | IEC 61169-47:2015 |
| Released: | 2015-03-30 |
| Language: | English/French - Bilingual |
IEC 61169-47:2015
IEC 61169-47:2015, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for RF coaxial connectors with clamp coupling, typically for use in 75 Ω cable networks (type F-Quick). It describes the interface dimensions with gauging information, electrical and mechanical performance including the mandatory tests selected from IEC 61169-1:2013, applicable to all DS relating to type F-Quick connectors. This specification indicates the recommended performance characteristics to be considered when writing a DS and covers test schedules and inspection requirements. This second edition cancels and replaces the first edition published in 2012. It constitutes a technical revision. The main changes are listed below: - Subclause 3.2 has been updated to better define gauging. - Table 2 has been updated for insertion and removal forces. - Clause 4 has been updated to refer to the new edition of IEC 61169-1.
